| 型号Model | ØD1 | ØD2 | H | R | E | F | B | A | X | Y | X1 | Y1 |
| PKD6-4-01 | 6 | 4 | 12 | 1/8 | 18 | 35.5 | 68.8 | 7 | 13.8 | 12.5 | 11.8 | 10.5 |
| PKD8-4-02 | 8 | 4 | 14 | 1/4 | 22.4 | 45.5 | 80.5 | 9 | 15.8 | 13.9 | 11.8 | 10.5 |
| PKD8-6-02 | 8 | 6 | 14 | 1/4 | 22.3 | 45.5 | 80.5 | 9 | 15.8 | 13.9 | 13.8 | 12.5 |
| PKD10-8-03 | 10 | 8 | 17 | 3/8 | 25.5 | 58.6 | 92.8 | 10 | 19.4 | 17 | 15.8 | 13.9 |
